IXTK180N15P دیتاشیت

IXTK180N15P

مشخصات دیتاشیت

نام دیتاشیت IXTK180N15P
حجم فایل 68.027 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

مشاهده دیتاشیت IXTK180N15P

دانلود دیتاشیت

سایر مستندات

IXTK180N15 2 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Littelfuse/IXYS IXTK180N15P
  • Operating Temperature: -55°C~+175°C@(Tj)
  • Power Dissipation (Pd): 800W
  • Total Gate Charge (Qg@Vgs): 240nC@10V
  • Drain Source Voltage (Vdss): 150V
  • Input Capacitance (Ciss@Vds): 7000pF@25V
  • Continuous Drain Current (Id): 180A
  • Gate Threshold Voltage (Vgs(th)@Id): 5V@500uA
  • Reverse Transfer Capacitance (Crss@Vds): -
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 10mΩ@90A,10V
  • Package: TO-264-3
  • Manufacturer: IXYS
  • Series: MegaMOS™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 150V
  • Current - Continuous Drain (Id) @ 25°C: 180A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 9mOhm @ 500mA, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 240nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 7000pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 730W (Tc)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-264 (IXTK)
  • Package / Case: TO-264-3, TO-264AA
  • detail: N-Channel 150V 180A (Tc) 730W (Tc) Through Hole TO-264 (IXTK)
