دیتاشیت DSEI2X61-12B

مشخصات دیتاشیت

دانلود دیتاشیت DSEI2X61-12B Type	DSEI2X61-12B Type Datasheet

RoHS: true
Category: Diodes/Diodes - Fast Recovery Rectifiers
Datasheet: Littelfuse/IXYS DSEI2X61-12B
Diode Configuration: 2 Independent
Reverse Voltage (Vr): 1.2kV
Operating Temperature: -40°C~+150°C@(Tvj)
Forward Voltage (Vf@If): 2.5V@60A
Reverse Leakage Current: 2.2mA@1.2kV
Reverse Recovery Time (trr): 40ns
Average Rectified Current (Io): 52A
Package: SOT-227
Manufacturer: IXYS
Series: FRED
Packaging: Tube
Part Status: Active
Diode Type: Standard
Voltage - DC Reverse (Vr) (Max): 1200V
Current - Average Rectified (Io) (per Diode): 52A
Voltage - Forward (Vf) (Max) @ If: 2.5V @ 60A
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr: 2.2mA @ 1200V
Mounting Type: Chassis Mount
Package / Case: SOT-227-4, miniBLOC
Supplier Device Package: SOT-227B
Base Part Number: DSEI2X
detail: Diode Array 2 Independent Standard 1200V 52A Chassis Mount SOT-227-4, miniBLOC
