دیتاشیت IXTA36N30P
مشخصات دیتاشیت
| نام دیتاشیت | IXT(A,P,Q)36N30P |
|---|---|
| حجم فایل | 300.442 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت IXT(A,P,Q)36N30P |
IXT(A,P,Q)36N30P Datasheet |
|---|
مشخصات
- Manufacturer: IXYS
- Series: PolarHT™
- Packaging: Tube
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 300V
- Current - Continuous Drain (Id) @ 25°C: 36A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 110mOhm @ 18A, 10V
- Vgs(th) (Max) @ Id: 5.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 70nC @ 10V
- Vgs (Max): ±30V
- Input Capacitance (Ciss) (Max) @ Vds: 2250pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 300W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: TO-263 (IXTA)
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- detail: N-Channel 300V 36A (Tc) 300W (Tc) Surface Mount TO-263 (IXTA)
