IXTA26P20P دیتاشیت

IXTA26P20P

مشخصات دیتاشیت

نام دیتاشیت IXTA26P20P
حجم فایل 84.106 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت IXTA26P20P

دانلود دیتاشیت

سایر مستندات

IX(T,H,P,Q)A26P20P 6 pages

مشخصات فنی

  • RoHS: true
  • Type: P Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Littelfuse/IXYS IXTA26P20P
  • Operating Temperature: -55°C~+175°C@(Tj)
  • Power Dissipation (Pd): 300W
  • Total Gate Charge (Qg@Vgs): 56nC@10V
  • Drain Source Voltage (Vdss): 200V
  • Input Capacitance (Ciss@Vds): 2740pF@25V
  • Continuous Drain Current (Id): 26A
  • Gate Threshold Voltage (Vgs(th)@Id): 4V@250uA
  • Reverse Transfer Capacitance (Crss@Vds): -
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 170mΩ@13A,10V
  • Package: TO-263
  • Manufacturer: IXYS
  • Series: PolarP™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 200V
  • Current - Continuous Drain (Id) @ 25°C: 26A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 170mOhm @ 13A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 56nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 2740pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 300W (Tc)
  • Mounting Type: Surface Mount
  • Supplier Device Package: TO-263 (IXTA)
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • detail: P-Channel 200V 26A (Tc) 300W (Tc) Surface Mount TO-263 (IXTA)
