دیتاشیت DSEK60-02A
مشخصات دیتاشیت
| نام دیتاشیت | DSEK60-02A/AR Type |
|---|---|
| حجم فایل | 104.744 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 2 |
دانلود دیتاشیت DSEK60-02A/AR Type |
DSEK60-02A/AR Type Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: Littelfuse/IXYS DSEK60-02A
- Diode Configuration: Dual Common Cathode
- Reverse Voltage (Vr): 200V
- Operating Temperature: -40°C~+150°C@(Tvj)
- Forward Voltage (Vf@If): 1.1V@30A
- Reverse Leakage Current: 200uA@200V
- Reverse Recovery Time (trr): 35ns
- Average Rectified Current (Io): 34A
- Package: TO-247AD
- Manufacturer: IXYS
- Series: FRED
- Packaging: Tube
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 200V
- Current - Average Rectified (Io) (per Diode): 34A
- Voltage - Forward (Vf) (Max) @ If: 1.1V @ 30A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 200µA @ 200V
- Operating Temperature - Junction: -40°C ~ 150°C
- Mounting Type: Through Hole
- Package / Case: TO-3P-3 Full Pack
- Supplier Device Package: TO-247AD
- detail: Diode Array 1 Pair Common Cathode Standard 200V 34A Through Hole TO-3P-3 Full Pack
