- Datasheet DSEI2X30-06C
DSEI2X30-06C Datasheet
Datasheet specifications
| Datasheet's name | DSEI2X30-06C |
|---|---|
| File size | 80.323 KB |
| File type | |
| Number of pages | 3 |
Download Datasheet DSEI2X30-06C |
Download Datasheet |
|---|
Other documentations
DSEI2X30(31)-04C/06C 3 pages
DSEI2X30-06C 3 pages
Technical specifications
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: Littelfuse/IXYS DSEI2X30-06C
- Diode Configuration: 2 Independent
- Reverse Voltage (Vr): 600V
- Forward Voltage (Vf@If): 1.6V@30A
- Reverse Leakage Current: 100uA@600V
- Reverse Recovery Time (trr): 50ns
- Average Rectified Current (Io): 30A
- Package: SOT-227
- Manufacturer: IXYS
- Series: -
- Packaging: Tube
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600V
- Current - Average Rectified (Io) (per Diode): 30A
- Voltage - Forward (Vf) (Max) @ If: 1.6V @ 30A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 100µA @ 600V
- Mounting Type: Chassis Mount
- Package / Case: SOT-227-4, miniBLOC
- Supplier Device Package: SOT-227B
- Base Part Number: DSEI2X
- detail: Diode Array 2 Independent Standard 600V 30A Chassis Mount SOT-227-4, miniBLOC
