دیتاشیت IXTH24N50L
مشخصات دیتاشیت
| نام دیتاشیت | IXTH/IXTM 21N50, 24N50 |
|---|---|
| حجم فایل | 691.596 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت IXTH/IXTM 21N50, 24N50 |
IXTH/IXTM 21N50, 24N50 Datasheet |
|---|
مشخصات
- Manufacturer: IXYS
- Series: MegaMOS™
- Packaging: Tube
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 500V
- Current - Continuous Drain (Id) @ 25°C: 24A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 230mOhm @ 12A, 10V
- Vgs(th) (Max) @ Id: 4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 190nC @ 10V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 4200pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 300W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-247 (IXTH)
- Package / Case: TO-247-3
- detail: N-Channel 500V 24A (Tc) 300W (Tc) Through Hole TO-247 (IXTH)
