IXYL40N250CV1 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IXYL40N250CV1
|
|
حجم فایل
|
235.886
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
Manufacturer:
IXYS
-
Series:
XPT™
-
Packaging:
Tube
-
Part Status:
Active
-
IGBT Type:
-
-
Voltage - Collector Emitter Breakdown (Max):
2500V
-
Current - Collector (Ic) (Max):
70A
-
Current - Collector Pulsed (Icm):
400A
-
Vce(on) (Max) @ Vge, Ic:
4V @ 15V, 40A
-
Power - Max:
577W
-
Switching Energy:
11.7mJ (on), 6.9mJ (off)
-
Input Type:
Standard
-
Gate Charge:
270nC
-
Td (on/off) @ 25°C:
21ns/200ns
-
Test Condition:
1250V, 40A, 1Ohm, 15V
-
Reverse Recovery Time (trr):
210ns
-
Operating Temperature:
-55°C ~ 175°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
ISOPLUSi5-Pak™
-
Supplier Device Package:
ISOPLUSi5-Pak™
-
detail:
IGBT 2500V 70A 577W Through Hole ISOPLUSi5-Pak™
