دیتاشیت IXTA10P50P-TRL

IXTx10P50P

مشخصات دیتاشیت

نام دیتاشیت IXTx10P50P
حجم فایل 188.12 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت IXTx10P50P

IXTx10P50P Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: PolarP™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 500V
  • Current - Continuous Drain (Id) @ 25°C: 10A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 1Ohm @ 5A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 50nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 2840pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 300W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: TO-263 (IXTA)
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • detail: P-Channel 500V 10A (Tc) 300W (Tc) Surface Mount TO-263 (IXTA)
