دیتاشیت DSEI12-06A

DSEI12-06A

مشخصات دیتاشیت

نام دیتاشیت DSEI12-06A
حجم فایل 136.414 کیلوبایت
نوع فایل pdf
تعداد صفحات 3

دانلود دیتاشیت DSEI12-06A

DSEI12-06A Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: Littelfuse/IXYS DSEI12-06A
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 600V
  • Operating Temperature: -40°C~+150°C@(Tvj)
  • Forward Voltage (Vf@If): 1.7V@16A
  • Reverse Leakage Current: 5uA@600V
  • Reverse Recovery Time (trr): 35ns
  • Average Rectified Current (Io): 14A
  • Package: TO-220-2
  • Manufacturer: IXYS
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 14A
  • Voltage - Forward (Vf) (Max) @ If: 1.7V @ 16A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 50µA @ 600V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-2
  • Supplier Device Package: TO-220AC
  • Operating Temperature - Junction: -40°C ~ 150°C
  • detail: Diode Standard 600V 14A Through Hole TO-220AC
