DSA120C150QB دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
DSA120C150QB
|
|
حجم فایل
|
135.717
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
IXYS DSA120C150QB
-
Reverse Voltage (Vr):
150V
-
Forward Voltage (Vf@If):
1.13V@120A
-
Average Rectified Current (Io):
60A
-
Package:
TO-3P-3
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Configuration:
1 Pair Common Cathode
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
150V
-
Current - Average Rectified (Io) (per Diode):
60A
-
Voltage - Forward (Vf) (Max) @ If:
930mV @ 60A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
1.8mA @ 150V
-
Operating Temperature - Junction:
-55°C ~ 175°C
-
Mounting Type:
Through Hole
-
Package / Case:
TO-3P-3, SC-65-3
-
Supplier Device Package:
TO-3P
-
detail:
Diode Array 1 Pair Common Cathode Schottky 150V 60A Through Hole TO-3P-3, SC-65-3
