DSEP2X60-12A 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: IXYS
- Series: HiPerFRED™
- Packaging: Tube
- Part Status: Active
- Diode Configuration: 2 Independent
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1200V
- Current - Average Rectified (Io) (per Diode): 60A
- Voltage - Forward (Vf) (Max) @ If: 2.42V @ 60A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 40ns
- Current - Reverse Leakage @ Vr: 1mA @ 1200V
- Mounting Type: Chassis Mount
- Package / Case: SOT-227-4, miniBLOC
- Supplier Device Package: SOT-227B
- Base Part Number: DSEP2X
- detail: Diode Array 2 Independent Standard 1200V 60A Chassis Mount SOT-227-4, miniBLOC
