MUBW15-12A7 Datasheet
Datasheet specifications
| Datasheet's name | MUBW15-12A7 |
|---|---|
| File size | 173.632 KB |
| File type | |
| Number of pages | 8 |
Download Datasheet MUBW15-12A7 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: -
- Packaging: Box
- Part Status: Active
- IGBT Type: NPT
- Configuration: Three Phase Inverter with Brake
- Voltage - Collector Emitter Breakdown (Max): 1200V
- Current - Collector (Ic) (Max): 35A
- Power - Max: 180W
- Vce(on) (Max) @ Vge, Ic: 2.6V @ 15V, 15A
- Current - Collector Cutoff (Max): 900µA
- Input Capacitance (Cies) @ Vce: 1nF @ 25V
- Input: Three Phase Bridge Rectifier
- NTC Thermistor: Yes
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: E2
- Supplier Device Package: E2
- Base Part Number: MUBW
- detail: IGBT Module NPT Three Phase Inverter with Brake 1200V 35A 180W Chassis Mount E2
