دیتاشیت VUO190-16NO7

VUO190-16NO7

مشخصات دیتاشیت

نام دیتاشیت VUO190-16NO7
حجم فایل 234.074 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت VUO190-16NO7

VUO190-16NO7 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Bridge Rectifiers
  • Datasheet: Littelfuse/IXYS VUO190-16NO7
  • Reverse Voltage (Vr): 1.6kV
  • Operating Temperature: -40°C~+150°C@(Tvj)
  • Forward Voltage (Vf@If): 1.36V@240A
  • Peak Forward Surge Current: 3.03kA
  • Reverse Leakage Current (Ir): 200uA@1.6kV
  • Average Rectified Current (Io): 240A
  • Package: -
  • Manufacturer: IXYS
  • Series: -
  • Packaging: Bulk
  • Part Status: Active
  • Diode Type: Three Phase
  • Technology: Standard
  • Voltage - Peak Reverse (Max): 1.6kV
  • Current - Average Rectified (Io): 248A
  • Voltage - Forward (Vf) (Max) @ If: 1.07V @ 80A
  • Current - Reverse Leakage @ Vr: 200µA @ 1600V
  • Mounting Type: Chassis Mount
  • Package / Case: PWS-E1
  • Supplier Device Package: PWS-E1
  • Base Part Number: VUO190
  • detail: Bridge Rectifier Three Phase Standard 1.6kV Chassis Mount PWS-E1
