DHG10I1200PM دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
DHG10I1200PM
|
|
حجم فایل
|
56.478
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Diodes - Fast Recovery Rectifiers
-
Datasheet:
Littelfuse/IXYS DHG10I1200PM
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
1.2kV
-
Operating Temperature:
-55°C~+150°C@(Tvj)
-
Forward Voltage (Vf@If):
2.22V@10A
-
Reverse Leakage Current:
15uA@1.2kV
-
Reverse Recovery Time (trr):
75ns
-
Average Rectified Current (Io):
10A
-
Package:
TO-220FP-2
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
1200V
-
Current - Average Rectified (Io):
10A
-
Voltage - Forward (Vf) (Max) @ If:
2.69V @ 10A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
15µA @ 1200V
-
Capacitance @ Vr, F:
-
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-2 Full Pack, Isolated Tab
-
Supplier Device Package:
TO-220FPAC
-
Operating Temperature - Junction:
-55°C ~ 150°C
-
detail:
Diode Standard 1200V 10A Through Hole TO-220FPAC
