دیتاشیت DSEP29-12A

DSEP29-12A

مشخصات دیتاشیت

نام دیتاشیت DSEP29-12A
حجم فایل 112.873 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت DSEP29-12A

DSEP29-12A Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: Littelfuse/IXYS DSEP29-12A
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 1.2kV
  • Operating Temperature: -55°C~+175°C@(Tvj)
  • Forward Voltage (Vf@If): 1.75V@30A
  • Reverse Leakage Current: 250uA@1.2kV
  • Reverse Recovery Time (trr): 60ns
  • Average Rectified Current (Io): 30A
  • Package: TO-220-2
  • Manufacturer: IXYS
  • Series: HiPerFRED™
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 1200V
  • Current - Average Rectified (Io): 30A
  • Voltage - Forward (Vf) (Max) @ If: 2.75V @ 30A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 250µA @ 1200V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-2
  • Supplier Device Package: TO-220AC
  • Operating Temperature - Junction: -55°C ~ 175°C
  • detail: Diode Standard 1200V 30A Through Hole TO-220AC
