MUBW15-12A6K 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: IXYS
- Series: -
- Packaging: Box
- Part Status: Obsolete
- IGBT Type: NPT
- Configuration: Three Phase Inverter with Brake
- Voltage - Collector Emitter Breakdown (Max): 1200V
- Current - Collector (Ic) (Max): 18A
- Power - Max: 70W
- Vce(on) (Max) @ Vge, Ic: 2.9V @ 15V, 10A
- Current - Collector Cutoff (Max): 500µA
- Input Capacitance (Cies) @ Vce: 850nF @ 25V
- Input: Three Phase Bridge Rectifier
- NTC Thermistor: Yes
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: E1
- Supplier Device Package: E1
- Base Part Number: MUBW
- detail: IGBT Module NPT Three Phase Inverter with Brake 1200V 18A 70W Chassis Mount E1
