- Datasheet VMM650-01F
VMM650-01F Datasheet
Datasheet specifications
| Datasheet's name | VMM650-01F |
|---|---|
| File size | 103.946 KB |
| File type | |
| Number of pages | 2 |
Download Datasheet VMM650-01F |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: HiPerFET™
- Packaging: Bulk
- Part Status: Active
- FET Type: 2 N-Channel (Dual)
- FET Feature: Standard
- Drain to Source Voltage (Vdss): 100V
- Current - Continuous Drain (Id) @ 25°C: 680A
- Rds On (Max) @ Id, Vgs: 2.2mOhm @ 500A, 10V
- Vgs(th) (Max) @ Id: 4V @ 30mA
- Gate Charge (Qg) (Max) @ Vgs: 1440nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds: -
- Power - Max: -
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: Y3-Li
- Supplier Device Package: Y3-Li
- Base Part Number: VMM
- detail: Mosfet Array 2 N-Channel (Dual) 100V 680A Chassis Mount Y3-Li
