دیتاشیت DSP8-08AS-TRL

DSP8-08AS

مشخصات دیتاشیت

نام دیتاشیت DSP8-08AS
حجم فایل 584.352 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت DSP8-08AS

DSP8-08AS Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Configuration: 1 Pair Series Connection
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 800V
  • Current - Average Rectified (Io) (per Diode): 11A
  • Voltage - Forward (Vf) (Max) @ If: 1.15V @ 7A
  • Speed: Standard Recovery >500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 5µA @ 800V
  • Operating Temperature - Junction: -55°C ~ 175°C
  • Mounting Type: Surface Mount
  • Package / Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
  • Supplier Device Package: TO-263 (D²Pak)
  • Base Part Number: DSP8-08
  • detail: Diode Array 1 Pair Series Connection Standard 800V 11A Surface Mount TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
