دیتاشیت IXTY8N70X2

IXTx8N70X2

مشخصات دیتاشیت

نام دیتاشیت IXTx8N70X2
حجم فایل 392.938 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت IXTx8N70X2

IXTx8N70X2 Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 700V
  • Current - Continuous Drain (Id) @ 25°C: 8A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 500mOhm @ 500mA, 10V
  • Vgs(th) (Max) @ Id: 5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 12nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 800pF @ 10V
  • FET Feature: -
  • Power Dissipation (Max): 150W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: TO-252
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • detail: N-Channel 700V 8A (Tc) 150W (Tc) Surface Mount TO-252
