DSEE29-12CC Datasheet
Datasheet specifications
| Datasheet's name | DSEE29-12CC |
|---|---|
| File size | 294.962 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet DSEE29-12CC |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: HiPerDynFRED™
- Packaging: Tube
- Part Status: Active
- Diode Configuration: 1 Pair Series Connection
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600V
- Current - Average Rectified (Io) (per Diode): 30A
- Voltage - Forward (Vf) (Max) @ If: 1.62V @ 30A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 35ns
- Current - Reverse Leakage @ Vr: 500µA @ 600V
- Operating Temperature - Junction: -55°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: ISOPLUS220™
- Supplier Device Package: ISOPLUS220™
- detail: Diode Array 1 Pair Series Connection Standard 600V 30A Through Hole ISOPLUS220™
