- Datasheet DSEP6-06BS
DSEP6-06BS-TRL Datasheet
Datasheet specifications
| Datasheet's name | DSEP6-06BS |
|---|---|
| File size | 122.948 KB |
| File type | |
| Number of pages | 4 |
Download Datasheet DSEP6-06BS |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: HiPerFRED™
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600V
- Current - Average Rectified (Io): 6A
- Voltage - Forward (Vf) (Max) @ If: 2.66V @ 6A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 15ns
- Current - Reverse Leakage @ Vr: 50µA @ 600V
- Capacitance @ Vr, F: 5pF @ 400V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: TO-252AA
- Operating Temperature - Junction: -55°C ~ 175°C
- Base Part Number: DSEP6-06
- detail: Diode Standard 600V 6A Surface Mount TO-252AA
