DSEP15-06B Datasheet

DSEP15-06B

Datasheet specifications

Datasheet's name DSEP15-06B
File size 52.127 KB
File type pdf
Number of pages 5

Download Datasheet DSEP15-06B

Download Datasheet

Other documentations

DSEP15-06B 5 pages

DSEP15-06B 1 pages

Technical specifications

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: Littelfuse/IXYS DSEP15-06B
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 600V
  • Operating Temperature: -55°C~+175°C@(Tvj)
  • Forward Voltage (Vf@If): 2.54V@15A
  • Reverse Leakage Current: 100uA@600V
  • Reverse Recovery Time (trr): 25ns
  • Average Rectified Current (Io): 15A
  • Package: TO-220-2
  • Manufacturer: IXYS
  • Series: HiPerFRED™
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 15A
  • Voltage - Forward (Vf) (Max) @ If: 2.52V @ 15A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 100µA @ 600V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-2
  • Supplier Device Package: TO-220AC
  • Operating Temperature - Junction: -55°C ~ 175°C
  • detail: Diode Standard 600V 15A Through Hole TO-220AC
