DSP8-12A Datasheet
Datasheet specifications
| Datasheet's name | DSP8-12A |
|---|---|
| File size | 137.177 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet DSP8-12A |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Diodes/Diodes - General Purpose
- Datasheet: IXYS DSP8-12A
- Diode Configuration: Dual
- Reverse Voltage (Vr): 1.2kV
- Forward Voltage (Vf@If): 1.35V@16A
- Reverse Leakage Current: 10uA@1.2kV
- Average Rectified Current (Io): 8A
- Package: TO-220
- Manufacturer: IXYS
- Series: -
- Packaging: Tube
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1200V
- Current - Average Rectified (Io) (per Diode): 11A
- Voltage - Forward (Vf) (Max) @ If: 1.15V @ 7A
- Speed: Standard Recovery >500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 5µA @ 1200V
- Operating Temperature - Junction: -55°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: DSP8-12
- detail: Diode Array 1 Pair Series Connection Standard 1200V 11A Through Hole TO-220-3
