دیتاشیت IXTP28P065T

IXT(A,P)28P065T

مشخصات دیتاشیت

نام دیتاشیت IXT(A,P)28P065T
حجم فایل 205.158 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت IXT(A,P)28P065T

IXT(A,P)28P065T Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: TrenchP™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 65V
  • Current - Continuous Drain (Id) @ 25°C: 28A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 45mOhm @ 14A, 10V
  • Vgs(th) (Max) @ Id: 4.5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 46nC @ 10V
  • Vgs (Max): ±15V
  • Input Capacitance (Ciss) (Max) @ Vds: 2030pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 83W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220AB
  • Package / Case: TO-220-3
  • detail: P-Channel 65V 28A (Tc) 83W (Tc) Through Hole TO-220AB
