دیتاشیت DSEC30-06A
مشخصات دیتاشیت
| نام دیتاشیت |
DSEC30-06A
|
| حجم فایل |
128.252
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Diodes - Fast Recovery Rectifiers
-
Datasheet:
Littelfuse/IXYS DSEC30-06A
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
600V
-
Operating Temperature:
-55°C~+150°C@(Tvj)
-
Forward Voltage (Vf@If):
2.03V@15A
-
Reverse Leakage Current:
100uA@600V
-
Reverse Recovery Time (trr):
35ns
-
Average Rectified Current (Io):
15A
-
Package:
TO-247-3
-
Manufacturer:
IXYS
-
Series:
HiPerFRED™
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
600V
-
Current - Average Rectified (Io) (per Diode):
15A
-
Voltage - Forward (Vf) (Max) @ If:
2.03V @ 15A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
100µA @ 600V
-
Operating Temperature - Junction:
-55°C ~ 175°C
-
Mounting Type:
Through Hole
-
Package / Case:
TO-3P-3 Full Pack
-
Supplier Device Package:
TO-247AD
-
detail:
Diode Array 1 Pair Common Cathode Standard 600V 15A Through Hole TO-3P-3 Full Pack
