DSA70C200HB دیتاشیت

DSA70C200HB

مشخصات دیتاشیت

نام دیتاشیت DSA70C200HB
حجم فایل 39.17 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت DSA70C200HB

دانلود دیتاشیت

سایر مستندات

DSA70C200HB 5 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: Littelfuse/IXYS DSA70C200HB
  • Diode Configuration: Dual Common Cathode
  • Reverse Voltage (Vr): 200V
  • Forward Voltage (Vf@If): 1.07V@70A
  • Reverse Leakage Current (Ir): 640uA@200V
  • Average Rectified Current (Io): 35A
  • Package: TO-247AD
  • Manufacturer: IXYS
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 200V
  • Current - Average Rectified (Io) (per Diode): 35A
  • Voltage - Forward (Vf) (Max) @ If: 930mV @ 35A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 640µA @ 200V
  • Operating Temperature - Junction: -55°C ~ 175°C
  • Mounting Type: Through Hole
  • Package / Case: TO-247-3
  • Supplier Device Package: TO-247AD
  • detail: Diode Array 1 Pair Common Cathode Schottky 200V 35A Through Hole TO-247-3
