IXTY48P05T دیتاشیت

IXTY48P05T

مشخصات دیتاشیت

نام دیتاشیت IXTY48P05T
حجم فایل 74.574 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

مشاهده دیتاشیت IXTY48P05T

دانلود دیتاشیت

سایر مستندات

IXT(Y,A,P)48P05T 7 pages

مشخصات فنی

  • RoHS: true
  • Type: P Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Littelfuse/IXYS IXTY48P05T
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 150W
  • Total Gate Charge (Qg@Vgs): 53nC@10V
  • Drain Source Voltage (Vdss): 50V
  • Input Capacitance (Ciss@Vds): 3660pF@25V
  • Continuous Drain Current (Id): 48A
  • Gate Threshold Voltage (Vgs(th)@Id): 4.5V@250uA
  • Reverse Transfer Capacitance (Crss@Vds): 215pF@25V
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 30mΩ@24A,10V
  • Package: TO-252
  • Manufacturer: IXYS
  • Series: TrenchP™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 50V
  • Current - Continuous Drain (Id) @ 25°C: 48A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 30mOhm @ 24A, 10V
  • Vgs(th) (Max) @ Id: 4.5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 53nC @ 10V
  • Vgs (Max): ±15V
  • Input Capacitance (Ciss) (Max) @ Vds: 3660pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 150W (Tc)
  • Mounting Type: Surface Mount
  • Supplier Device Package: TO-252
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • detail: P-Channel 50V 48A (Tc) 150W (Tc) Surface Mount TO-252
