دیتاشیت DSEI60-10A

DSEI60-10A

مشخصات دیتاشیت

نام دیتاشیت DSEI60-10A
حجم فایل 82.359 کیلوبایت
نوع فایل pdf
تعداد صفحات 2

دانلود دیتاشیت DSEI60-10A

DSEI60-10A Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: Littelfuse/IXYS DSEI60-10A
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 1kV
  • Operating Temperature: -40°C~+150°C@(Tvj)
  • Forward Voltage (Vf@If): 2.3V@60A
  • Reverse Leakage Current: 3mA@1kV
  • Reverse Recovery Time (trr): 35ns
  • Average Rectified Current (Io): 60A
  • Package: TO-247-2
  • Manufacturer: IXYS
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 1000V
  • Current - Average Rectified (Io): 60A
  • Voltage - Forward (Vf) (Max) @ If: 2.3V @ 60A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 3mA @ 1000V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: TO-247-2
  • Supplier Device Package: TO-247AD
  • Operating Temperature - Junction: -40°C ~ 150°C
  • detail: Diode Standard 1000V 60A Through Hole TO-247AD
