- Datasheet DSP8-12S
DSP8-12S-TUB Datasheet
Datasheet specifications
| Datasheet's name | DSP8-12S |
|---|---|
| File size | 161.105 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet DSP8-12S |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: -
- Packaging: Tube
- Part Status: Active
- Diode Configuration: 1 Pair Series Connection
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1200V
- Current - Average Rectified (Io) (per Diode): 11A
- Voltage - Forward (Vf) (Max) @ If: 1.15V @ 7A
- Speed: Standard Recovery >500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 5µA @ 1200V
- Operating Temperature - Junction: -55°C ~ 175°C
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: TO-263 (D²Pak)
- Base Part Number: DSP8-12
- detail: Diode Array 1 Pair Series Connection Standard 1200V 11A Surface Mount TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
