- IXGK50N60B2D1
IXGK50N60B2D1 Datasheet
Datasheet specifications
| Datasheet's name | IXGK50N60B2D1 |
|---|---|
| File size | 648.438 KB |
| File type | |
| Number of pages | 6 |
Download Datasheet IXGK50N60B2D1 |
Download Datasheet |
|---|
Other documentations
IXG(H,K,J,T)50N60B 4 pages
Technical specifications
- Manufacturer: IXYS
- Series: HiPerFAST™
- Packaging: Bulk
- Part Status: Obsolete
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 600V
- Current - Collector (Ic) (Max): 75A
- Current - Collector Pulsed (Icm): 200A
- Vce(on) (Max) @ Vge, Ic: 2.3V @ 15V, 50A
- Power - Max: 300W
- Switching Energy: 3mJ (off)
- Input Type: Standard
- Gate Charge: 160nC
- Td (on/off) @ 25°C: 50ns/150ns
- Test Condition: 480V, 50A, 2.7Ohm, 15V
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-264-3, TO-264AA
- Supplier Device Package: TO-264 (IXGK)
- Base Part Number: IXG*50N60
- detail: IGBT 600V 75A 300W Through Hole TO-264 (IXGK)
