دیتاشیت FMP76-01T
مشخصات دیتاشیت
| نام دیتاشیت |
FMP76-010T
|
| حجم فایل |
109.474
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
FET Type:
N and P-Channel, Common Drain
-
FET Feature:
Standard
-
Drain to Source Voltage (Vdss):
100V
-
Current - Continuous Drain (Id) @ 25°C:
54A (Tc), 62A (Tc)
-
Rds On (Max) @ Id, Vgs:
24mOhm @ 38A, 10V, 11mOhm @ 25A, 10V
-
Vgs(th) (Max) @ Id:
4V @ 250µA, 4.5V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
197nC @ 10V, 104nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
1370pF @ 25V, 5080pF @ 25V
-
Power - Max:
89W, 132W
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
ISOPLUSi5-Pak™
-
Supplier Device Package:
ISOPLUS i4-PAC™
-
detail:
Mosfet Array N and P-Channel, Common Drain 100V 54A (Tc), 62A (Tc) 89W, 132W Through Hole ISOPLUS i4-PAC™
