FMP36-015P دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FMP36-015P	دانلود دیتاشیت

Manufacturer: IXYS
Series: Polar™
Packaging: Tube
Part Status: Active
FET Type: N and P-Channel
FET Feature: Standard
Drain to Source Voltage (Vdss): 150V
Current - Continuous Drain (Id) @ 25°C: 36A, 22A
Rds On (Max) @ Id, Vgs: 40mOhm @ 31A, 10V
Vgs(th) (Max) @ Id: 5.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 70nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 2250pF @ 25V
Power - Max: 125W
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Through Hole
Package / Case: i4-Pac™-5
Supplier Device Package: ISOPLUS i4-PAC™
detail: Mosfet Array N and P-Channel 150V 36A, 22A 125W Through Hole ISOPLUS i4-PAC™
