VWO35-08HO7 Datasheet
Datasheet specifications
| Datasheet's name | VWO35-08HO7 |
|---|---|
| File size | 293.803 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet VWO35-08HO7 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: IXYS
- Series: -
- Packaging: Bulk
- Part Status: Active
- Structure: 3-Phase Controller - All SCRs
- Number of SCRs, Diodes: 6 SCRs
- Voltage - Off State: 800V
- Current - On State (It (AV)) (Max): 16A
- Current - On State (It (RMS)) (Max): 35A
- Voltage - Gate Trigger (Vgt) (Max): 1.5V
- Current - Gate Trigger (Igt) (Max): 65mA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 200A, 210A
- Current - Hold (Ih) (Max): 50mA
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: Module
- Base Part Number: VWO
- detail: SCR Module 800V 35A 3-Phase Controller - All SCRs Chassis Mount Module
