دیتاشیت IXTH75N15

IXT(H,T)75N15

مشخصات دیتاشیت

نام دیتاشیت IXT(H,T)75N15
حجم فایل 597.643 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت IXT(H,T)75N15

IXT(H,T)75N15 Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 150V
  • Current - Continuous Drain (Id) @ 25°C: 75A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 23mOhm @ 500mA, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 210nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 5400pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 330W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247 (IXTH)
  • Package / Case: TO-247-3
  • detail: N-Channel 150V 75A (Tc) 330W (Tc) Through Hole TO-247 (IXTH)
