دیتاشیت GMM3X60-015X2-SMDSAM

مشخصات دیتاشیت

دانلود دیتاشیت GMM3x60-015X2	GMM3x60-015X2 Datasheet

Manufacturer: IXYS
Series: -
Packaging: Tray
Part Status: Obsolete
FET Type: 6 N-Channel (3-Phase Bridge)
FET Feature: Standard
Drain to Source Voltage (Vdss): 150V
Current - Continuous Drain (Id) @ 25°C: 50A
Rds On (Max) @ Id, Vgs: 24mOhm @ 38A, 10V
Vgs(th) (Max) @ Id: 4.5V @ 1mA
Gate Charge (Qg) (Max) @ Vgs: 97nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 5800pF @ 25V
Power - Max: -
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Package / Case: ISOPLUS-DIL™
Supplier Device Package: ISOPLUS-DIL™
detail: Mosfet Array 6 N-Channel (3-Phase Bridge) 150V 50A Surface Mount ISOPLUS-DIL™
