دیتاشیت GWM100-0085X1-SMD

مشخصات دیتاشیت

دانلود دیتاشیت GWM100-0085X1	GWM100-0085X1 Datasheet

Manufacturer: IXYS
Series: -
Packaging: Tube
Part Status: Active
FET Type: 6 N-Channel (3-Phase Bridge)
FET Feature: Standard
Drain to Source Voltage (Vdss): 85V
Current - Continuous Drain (Id) @ 25°C: 103A
Rds On (Max) @ Id, Vgs: 6.2mOhm @ 75A, 10V
Vgs(th) (Max) @ Id: 4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 114nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: -
Power - Max: -
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Package / Case: 17-SMD, Gull Wing
Supplier Device Package: ISOPLUS-DIL™
Base Part Number: GWM100
detail: Mosfet Array 6 N-Channel (3-Phase Bridge) 85V 103A Surface Mount ISOPLUS-DIL™
