دیتاشیت GWM100-01X1

مشخصات دیتاشیت

GWM100-01X1	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: IXYS
Series: -
Packaging: Tube
Part Status: Obsolete
FET Type: 6 N-Channel (3-Phase Bridge)
FET Feature: Standard
Drain to Source Voltage (Vdss): 100V
Current - Continuous Drain (Id) @ 25°C: 90A
Rds On (Max) @ Id, Vgs: 8.5mOhm @ 80A, 10V
Vgs(th) (Max) @ Id: 4.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 90nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: -
Power - Max: -
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Package / Case: 17-SMD, Flat Leads
Supplier Device Package: ISOPLUS-DIL™
Base Part Number: GWM100
detail: Mosfet Array 6 N-Channel (3-Phase Bridge) 100V 90A Surface Mount ISOPLUS-DIL™
