دیتاشیت GWM180-004X2-SMD
مشخصات دیتاشیت
| نام دیتاشیت |
GWM180-004X2
|
| حجم فایل |
730.68
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
FET Type:
6 N-Channel (3-Phase Bridge)
-
FET Feature:
Standard
-
Drain to Source Voltage (Vdss):
40V
-
Current - Continuous Drain (Id) @ 25°C:
180A
-
Rds On (Max) @ Id, Vgs:
2.5mOhm @ 100A, 10V
-
Vgs(th) (Max) @ Id:
4.5V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
110nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
-
-
Power - Max:
-
-
Operating Temperature:
-55°C ~ 175°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
17-SMD, Gull Wing
-
Supplier Device Package:
ISOPLUS-DIL™
-
detail:
Mosfet Array 6 N-Channel (3-Phase Bridge) 40V 180A Surface Mount ISOPLUS-DIL™
