دیتاشیت MKE38RK600DFEL-TUB
مشخصات دیتاشیت
نام دیتاشیت | MKE38RK600DFELB |
---|---|
حجم فایل | 397.159 کیلوبایت |
نوع فایل | |
تعداد صفحات | 7 |
دانلود دیتاشیت MKE38RK600DFELB |
MKE38RK600DFELB Datasheet |
---|
مشخصات
- Manufacturer: IXYS
- Series: CoolMOS™
- Packaging: Tray
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 600V
- Current - Continuous Drain (Id) @ 25°C: 50A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 45mOhm @ 44A, 10V
- Vgs(th) (Max) @ Id: 3.5V @ 3mA
- Gate Charge (Qg) (Max) @ Vgs: 190nC @ 10V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 6800pF @ 100V
- FET Feature: -
- Power Dissipation (Max): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: ISOPLUS-SMPD™.B
- Package / Case: 9-SMD Module
- detail: N-Channel 600V 50A (Tc) Surface Mount ISOPLUS-SMPD™.B
