دیتاشیت VHFD29-14IO1
مشخصات دیتاشیت
| نام دیتاشیت |
VHFD 29
|
| حجم فایل |
87.945
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
3
|
مشخصات
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Structure:
Bridge, Single Phase - SCRs/Diodes (Layout 1)
-
Number of SCRs, Diodes:
2 SCRs, 4 Diodes
-
Voltage - Off State:
1.4kV
-
Current - On State (It (AV)) (Max):
28A
-
Voltage - Gate Trigger (Vgt) (Max):
1V
-
Current - Gate Trigger (Igt) (Max):
65mA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
300A, 330A
-
Current - Hold (Ih) (Max):
100mA
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
V1A-PAK
-
Base Part Number:
VHFD
-
detail:
SCR Module 1.4kV Bridge, Single Phase - SCRs/Diodes (Layout 1) Chassis Mount V1A-PAK
