MMIX1F44N100Q3 数据手册
其他文档
SMPD Product Brief 5 pages
技术规格
- Manufacturer: IXYS
- Series: HiPerFET™
- Packaging: Tube
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 1000V
- Current - Continuous Drain (Id) @ 25°C: 30A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 245mOhm @ 22A, 10V
- Vgs(th) (Max) @ Id: 6.5V @ 8mA
- Gate Charge (Qg) (Max) @ Vgs: 264nC @ 10V
- Vgs (Max): ±30V
- Input Capacitance (Ciss) (Max) @ Vds: 13600pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 694W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 24-SMPD
- Package / Case: 24-PowerSMD, 21 Leads
- detail: N-Channel 1000V 30A (Tc) 694W (Tc) Surface Mount 24-SMPD
