دیتاشیت MUBW15-06A7

MUBW15-06A7

مشخصات دیتاشیت

نام دیتاشیت MUBW15-06A7
حجم فایل 798.916 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت MUBW15-06A7

MUBW15-06A7 Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: -
  • Packaging: Box
  • Part Status: Active
  • IGBT Type: NPT
  • Configuration: Three Phase Inverter with Brake
  • Voltage - Collector Emitter Breakdown (Max): 600V
  • Current - Collector (Ic) (Max): 25A
  • Power - Max: 100W
  • Vce(on) (Max) @ Vge, Ic: 2.3V @ 15V, 15A
  • Current - Collector Cutoff (Max): 600µA
  • Input Capacitance (Cies) @ Vce: 0.8nF @ 25V
  • Input: Three Phase Bridge Rectifier
  • NTC Thermistor: Yes
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Chassis Mount
  • Package / Case: E2
  • Supplier Device Package: E2
  • Base Part Number: MUBW
  • detail: IGBT Module NPT Three Phase Inverter with Brake 600V 25A 100W Chassis Mount E2
