VMO60-05F 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: IXYS
- Series: HiPerFET™
- Packaging: Bulk
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 500V
- Current - Continuous Drain (Id) @ 25°C: 60A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 75mOhm @ 500mA, 10V
- Vgs(th) (Max) @ Id: 4V @ 24mA
- Gate Charge (Qg) (Max) @ Vgs: 405nC @ 10V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 12600pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 590W (Tc)
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Chassis Mount
- Supplier Device Package: TO-240AA
- Package / Case: TO-240AA
- Base Part Number: VMO
- detail: N-Channel 500V 60A (Tc) 590W (Tc) Chassis Mount TO-240AA
