VKM60-01P1 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت VKM60-01P1	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: IXYS
Series: HiPerFET™
Packaging: Bulk
Part Status: Not For New Designs
FET Type: 4 N-Channel (H-Bridge)
FET Feature: Standard
Drain to Source Voltage (Vdss): 100V
Current - Continuous Drain (Id) @ 25°C: 75A
Rds On (Max) @ Id, Vgs: 25mOhm @ 500mA, 10V
Vgs(th) (Max) @ Id: 4V @ 4mA
Gate Charge (Qg) (Max) @ Vgs: 260nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 4500pF @ 25V
Power - Max: 300W
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Through Hole
Package / Case: ECO-PAC2
Supplier Device Package: ECO-PAC2
detail: Mosfet Array 4 N-Channel (H-Bridge) 100V 75A 300W Through Hole ECO-PAC2
