MKI75-06A7 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: IXYS
- Series: -
- Packaging: Box
- Part Status: Active
- IGBT Type: NPT
- Configuration: Full Bridge Inverter
- Voltage - Collector Emitter Breakdown (Max): 600V
- Current - Collector (Ic) (Max): 90A
- Power - Max: 280W
- Vce(on) (Max) @ Vge, Ic: 2.6V @ 15V, 75A
- Current - Collector Cutoff (Max): 1.3mA
- Input Capacitance (Cies) @ Vce: 3.2nF @ 25V
- Input: Standard
- NTC Thermistor: Yes
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: E2
- Supplier Device Package: E2
- Base Part Number: MKI
- detail: IGBT Module NPT Full Bridge Inverter 600V 90A 280W Chassis Mount E2
