دیتاشیت MCD200-14IO1
مشخصات دیتاشیت
| نام دیتاشیت |
MCD200-14IO1
|
| حجم فایل |
258.921
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Structure:
Series Connection - SCR/Diode
-
Number of SCRs, Diodes:
1 SCR, 1 Diode
-
Voltage - Off State:
1.4kV
-
Current - On State (It (AV)) (Max):
216A
-
Current - On State (It (RMS)) (Max):
340A
-
Voltage - Gate Trigger (Vgt) (Max):
2V
-
Current - Gate Trigger (Igt) (Max):
150mA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
8000A, 8600A
-
Current - Hold (Ih) (Max):
150mA
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Chassis Mount
-
Package / Case:
Y4-M6
-
Base Part Number:
MC*200
-
detail:
SCR Module 1.4kV 340A Series Connection - SCR/Diode Chassis Mount Y4-M6
