دیتاشیت IXTK33N50

IXTK33N50

مشخصات دیتاشیت

نام دیتاشیت IXTK33N50
حجم فایل 143.475 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت IXTK33N50

IXTK33N50 Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 500V
  • Current - Continuous Drain (Id) @ 25°C: 33A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 170mOhm @ 500mA, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 250nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 4900pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 416W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-264 (IXTK)
  • Package / Case: TO-264-3, TO-264AA
  • detail: N-Channel 500V 33A (Tc) 416W (Tc) Through Hole TO-264 (IXTK)
