IXFR32N100P دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IXFR32N100P
|
|
حجم فایل
|
113.68
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
Manufacturer:
IXYS
-
Series:
HiPerFET™, PolarP2™
-
Packaging:
Tube
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
1000V
-
Current - Continuous Drain (Id) @ 25°C:
18A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
340mOhm @ 16A, 10V
-
Vgs(th) (Max) @ Id:
6.5V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
225nC @ 10V
-
Vgs (Max):
±30V
-
Input Capacitance (Ciss) (Max) @ Vds:
14200pF @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
320W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
ISOPLUS247™
-
Package / Case:
ISOPLUS247™
-
detail:
N-Channel 1000V 18A (Tc) 320W (Tc) Through Hole ISOPLUS247™
