MMIX2F60N50P3 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MMIX2F60N50P3	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: IXYS
Series: HiPerFET™, Polar3™
Packaging: Tube
Part Status: Active
FET Type: 2 N-Channel (Dual)
FET Feature: Standard
Drain to Source Voltage (Vdss): 500V
Current - Continuous Drain (Id) @ 25°C: 30A (Tc)
Rds On (Max) @ Id, Vgs: 110mOhm @ 30A, 10V
Vgs(th) (Max) @ Id: 5V @ 4mA
Gate Charge (Qg) (Max) @ Vgs: 96nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 6250pF @ 25V
Power - Max: 320W
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 24-SMD Module, 9 Leads
Supplier Device Package: 24-SMPD
detail: Mosfet Array 2 N-Channel (Dual) 500V 30A (Tc) 320W Surface Mount 24-SMPD
